6" Round Wafer LED Panel 0-10V
6" Round Wafer LED Panel 0-10V
by Elco
SKU:ELSP63DXCT3W
Regular price
$41.96
Regular price
Sale price
$41.96
Unit price
per
0-10V Dimmable edge-lit LED technology with glare control lens for even glow.
Key Features:
- Fits 3 1/2" and 4" Octagon and Round junction boxes
- 120/277V, 0-10V Dimmable
- Switch to desire CCT: 3000K, 3500K, 4000K
- Edge-lit LED technology
- Glare controlled lens
- IC Rated and Wet Location Rated
- JA8 2022 E-Compliant
- ETL Listed
- 7 3/8" O.D. x 5/8" H
Typically ships in 1-3 business days based on stock levels
Quick Ship
In stock: 0
🖨️ Print as PDF
×
Send a copy to email:
By entering your email, you agree that it will be seen by the store owner and may contact you.
Open here
- Description
- Specifications
- Resources
0-10V Dimmable edge-lit LED technology with glare control lens for even glow.
Key Features:
- Fits 3 1/2" and 4" Octagon and Round junction boxes
- 120/277V, 0-10V Dimmable
- Switch to desire CCT: 3000K, 3500K, 4000K
- Edge-lit LED technology
- Glare controlled lens
- IC Rated and Wet Location Rated
- JA8 2022 E-Compliant
- ETL Listed
- 7 3/8" O.D. x 5/8" H
| Mounting |
Surface
|
| Size |
|
| Finish |
White/Black
|
| Wattage |
14W
|
| Lumens |
1000L
|
| Voltage |
120/277V
|
| Color Temp |
30K/40K/50K
|
| Dimmable |
0-10V
|
| CRI |
90+
|
| Listing |
JA8 2022 E-Compliant, ETL Listed
|
| Location Rating |
Wet Location Suitable For Indoor/Outdoor Use
|
