8" Round Sky Panel LED, 0-10V

8" Round Sky Panel LED, 0-10V

by Elco

SKU:ELSP83DXCT3W

$80.92
$80.92
Sale Sold out

0-10V Dimmable edge-lit LED technology with glare control lens for even glow.

Key Features:
  • Fits 4" Octagon and Square junction boxes (1 1/2" Minimum in depth)
  • Fits 4" and 6" housings and optional mounting accessories
  • 120/277V, 0-10V Dimmable
  • Switch to desire CCT: 3000K, 3500K, 4000K
  • Edge-lit LED technology
  • Glare controlled lens
  • IC Rated and Wet Location Rated
  • JA8 2022 E-Compliant
  • ETL Listed
  • 9" O.D. x 5/8" H
Color: White
Typically ships in 1-3 business days based on stock levels Quick Ship

In stock: 0
  • Resources
Mfr Spec Sheet
Installation Instructions
Warranty Information
View full details
  • Specifications
Mounting
Surface
Size
  • 9" O.D. x 5/8" H
Finish
White/Black
Wattage
17W
Lumens
1400L
Voltage
120/277V
Color Temp
30K/40K/50K
Dimmable
0-10V
CRI
90+
Listing
JA8 2022 E-Compliant, ETL Listed
Location Rating
Wet Location Suitable For Indoor/Outdoor Use
Data Sheet
Manufacturer Data Sheet
Installation Instructions
